Wiring diagram for CAN bus system - example -
– continued –
■
Connect screen only to the respective terminals and to the central earthing point (CEP).
■
The rated voltage is indicated on the name plate.
■
When switching off inductive loads, voltage spikes are produced that may impair the op-
eration of control and measuring systems. Connected contactors must therefore be pro-
vided with suppressors such as RC combinations.
■
In the event of an alarm the signal output (terminal 7 and 8) is instantaneously closed.
■
In the event of a malfunction the signal output (terminals 7 and 8) is opened and closed
in a clock-pulse controlled way in order to ensure an optical differentiation between an
alarm and a malfunction signal. If required you can wire terminals 7 and 8 with an exter-
nal signal lamp.
Tools
■
Screwdriver for slotted screws, size 2.5, completely insulated according to VDE 0680-1
■
Screwdriver for cross head screws, size 2
Basic Settings
Fac tory settings
Control unit NRS 1-40.1
The control unit features the following factory set default values:
■
Node ID: 1
■
Baud rate: 250 kBit/s (125 m cable length)
■
De-energizing delay: 3 sec.
■
Configuration: Operation with two level electrodes NRG 1x-40, one level electrode NRG 1x-41.1 and
one temperature transmitter TRV 5-40.
