19
PARAMETER DESCRIPTION
Setup
• Press ENTER to enter select mode. Select mode is
indicated by “ * ”
• Press ENTER to confirm choice
Empty:
No selection
Custom:
For future configuration
Stereo analog:
Two monitor stereo setup with analog* Inputs selected.
Stereo Digital:
Two monitor stereo setup with digital Inputs selected.
5.1 Analog:
5.1 setup with analog* Inputs selected.
5.1 Digital
5.1 setup with digital Inputs selected.
6.1 Analog
5.1 Setup + Center surround on a separate channel gives
the 6.1 setup.
6.1 Digital
5.1 Setup + Center surround on a separate channel gives
the 6.1 setup.
5.3 Analog
Analog setup with 5 monitors and 3 subs
5.3 Digital
Digital setup with 5 monitors and 3 subs
* Analog Inputs are only available with an optional analog
card installed.
5.1 Digital/6 Master
5.1 Setup using one Master with optional Digital I/o card
installed, 4 slave monitors (or masters set as slave) and 1
sub.
External Clock
• Press ENTER to access sub-menus
BNC Sync On:
The monitor attempts to lock on the Word Clock BNC.
BNC Sync Off:
The monitor will attempt to lock on the AES Input.
Calibrate Monitor
• Press ENTER
• Select monitor to calibrate using the ARROW keys
• Press ENTER
No Task
L Front
R Front
Center
(C) SUB
L Sur
R Sur C Sur
L SUB
R SUB
LS Chain
RS Chain
L Inner
R Inner
Custom 1-4
Reserved for
future use
Following tasks can be given:
Setup Menu
• Press ENTER to access sub-menus
Set Monitor Task
For the System Controller - Master monitor to identify and
operate all monitors in the setup, each monitor must be
given one of the following tasks indicating function and
position.
• Press ENTER to access task options
• Use ARROW keys to select task
• Press ENTER to confirm selected task
