Supplement 1 – ACCESS I and M DeviceNet Specification

3

(4) Bus Off Counter will be forced to 0 whenever set regardless of the

data value provided.

(5) Allocation_byte

bit 0

explicit – set to 1 to allocate

bit 1

polled – set to 1 to allocate

bit 2-3

reserved (always 0)

bit 4

change of state – set to 1 to allocate

bit 5

cyclic – set to 1 to allocate

bit 6

unacknowledged COS/Cyclic

bit 7

reserved (always 0)

Assembly Object
Class Code: 04 (0x04)

The Assembly Objects bind attributes of multiple objects to allow data
to or from each object to be sent or received over a single connection.

Assembly Object Class Attributes

Attribute

Access

Name

Type

Value

1

Get

Revision

UINT

1

2

Get

Max Class ID

UINT

(1)

Assembly Object, Instance (1) Attributes (Produced Data)

Attribute Access

Name

Type

Value

3

Get

Data

ARRAY of

(2)

BYTE
ULONG
ULONG
USINT
USINT

Assembly Object, Instance (1) Attributes (Consumed Data)

Attribute Access

Name

Type

Value

3

Get/Set

Data

BYTE

(3)

Common Services

Service Code

Class

Instance

Service Name

14 (0x0E)

Yes

Yes

Get_Attribute_Single

16 (0x10)

No

Yes

Set_Attribute_Single

(1) Max Class ID:

Assembly Input Object

101 or TBD

Assembly Output Object

102 or TBD

Max Class ID is the max value of Assembly Input Object and
Assembly Output Object.
(2) Produced Data:

bit

0 = Sensor1

(DIP instance 1 state)

bit

1 = Sensor2

(DIP instance 2 state)

bit

2 = Sensor3

(DIP instance 3 state)

bit

3 = LB/SC Selenoid1 (DOP instance 1 status)

bit

4 = LB/SC Selenoid2 (DOP instance 2 status)

bit

5 = Not Used

bit

6 = Not Used

bit

7 = Not Used

bytes

2-5 = Maintenance counter

bytes

6-9 = Cumulative counter

bytes

10 = Cycle timer "open": in sec

bytes

11 = Cycle timer "close": in sec

(3) Consumed Data:

bit

0 = Not used

bit

1 = Not used

bit

2 = Not used

bit

3 = Not used

bit

4 = Not used

bit

5 = Solenoid 1

(DOP instance 1 state)

bit

6 = Solenoid 2

(DOP instance 2 state)

bit

7 = Reset Counter

(UDO instance 1 reset
counter)

Connection Object
Class Code: 05 (0x05)

The Connection Objects manage the characteristics of each
communication connection. As a Group II Only Slave device the unit
supports one explicit message connection, a POLL message
connection.

Connection Object Class Attributes

Attribute

Access

Name

Type

Value

1

Get

Revision

UINT

1

Connection Object, Instance 1 Attributes (Explicit Message)

Attribute

Access

Name

Type

Value

1

Get

State

USINT

(1)

2

Get

Instance Type

USINT

0 = Explicit
Message

3

Get

Transport Class Trigger

USINT

0x83

4

Get

Prod. Conn. ID

UINT

(2)

5

Get

Cons. Conn. ID

UINT

(2)

6

Get

Initial Comm. Char.

USINT

0x21

7

Get

Prod. Conn. Size

UINT

128

8

Get

Cons. Conn. Size

UINT

133

9

Get

Expected Packet Rate

UINT

default
2500msec

12

Get

Watchdog Timeout Act.

USINT

1= autodel

13

Get

Prod. Conn. Path Length USINT

0

14

Get

Prod. Conn. Path

USINT

(null)

15

Get

Cons. Conn. Path Length USINT

0

16

Get

Cons. Conn. Path

USINT

(null)

Flow Control

Worcester Controls
