63
MX/DDC-100 Field Unit Installation and Maintenance FCD LMENIM2329-01 – 03/11
flowserve.com
System Integrator Tasks
Deliverable From To Comments
Specification Engineer S.I Detail functionality of system
Schedule Contractor S.I. Production Schedule
Manuals Limitorque S.I.
Manuals for DDC-100 Operation:
• LMAIM4019 Direct-to-Host Programming Guide
• LMAIM1329 Accutronix Installation and Operation for MX-DDC Field Unit
• LMAIM4029 DDC-100 UEC Field Unit (Modbus) Installation and Operation
Manual
• LMAIM4030 DDC-100 UEC Field Unit Installation and Commissioning
Manual
• LMAIM4022 DDC-100 UEC Field Unit Wiring and Startup Guidelines
• Modicon Modbus Protocol Reference Guide PI-MODBUS-300 Rev. G
(available from Modicon)
Hardware for
system development Contractor
S.I. Hardware may include: DDC-100 Field Units, RS-232/485 converters
Fourth-Party
Hardware/Software
Component
supplier
S.I.
Modbus interface modules, Modbus drivers, non-Limitorque converters, or
surge suppression
Actuator Contractor S.I. Availability of DDC-100 Field Unit for testing developed application software
Site Preparation Contractor S.I.
Complete actuator or field unit installation. Provide actual (as installed) site
loop diagram to System Integrator
Operational System S.I. Contractor Software only (code) or Hardware and Software (hardware and code)
Documentation S.I. Contractor
System Operation and Maintenance Manuals, Operational characteristics of
system, Network Addresses to equipment tag names
Engineer Tasks
Deliverable From To Comments
Specification End-user Engineer Site and system requirements
Schedule End-user Engineer Production Schedule. Completion dates
Sales Support Limitorque Engineer Information on Limitorque products
Manuals Limitorque Engineer
Manuals for DDC-100 Operation:
• LMAIM4019 Direct-to-Host Programming Guide
• LMAIM1329 Accutronix Installation and Operation for MX-DDC Field Unit
• LMAIM4029 DDC-100 UEC Field Unit (Modbus) Installation and Operation
Manual
• LMAIM4030 DDC-100 UEC Field Unit Installation and Commissioning
Manual
• LMAIM4022 DDC-100 UEC Field Unit Wiring and Startup Guidelines
• Modicon Modbus Protocol Reference Guide PI-MODBUS-300 Rev. G
(available from Modicon)
Project
Specification
Engineer
Contractor, S/I,
OEM,Limitorque Provide operational specifications for all equipment and service providers
Project
Responsibility
Engineer Contractor Define which supplier is responsible for each portion of project
P&ID Engineer Contractor
Detailed layout and instructions for building site. Information should include
actuator tag names, required data points from actuator, field unit, and field
wiring
Site Electrical
and electronics
Engineer Contractor
Detail site electrical requirements, cable type, layout, and locations. Voltages
available for equipment
Loop Drawings Engineer Contractor
Detail cable routings from Host to each field device. This defines how the
network cable is to run throughout the facility
