Page 11
11
KOR-61151 WIRING DIAGRAM
POWER SUPPLY :
PRIMARY
INTERLOCK
SWITCH(UPPER)
TIMER
SWITCH
TIMER ASS'Y
V.P.C
.
CAVITY
THERMOSTAT
INTERLOCK
MONITOR
SWITCH
HIGH VOLTAGE
TRANSFORMER
H.V.
CAPACITOR
H.V. DIODE
MAGNETRON
WH
RD
BK
WH
GN
WH
BK
BL
GY
GY
GY
GY
GY
GY
CL
GM
FM
SECONDARY
INTERLOCK SWITCH
NOTE :
RD
: RED
WH :
WHITE
BK :
BLACK
GN : GREEN
BR :
BROWN
OR :
ORANGE
BL :
BLUE
GY : GRAY
GE : GREEN/YELLOW
CL
: CAVITY LAMP
FM
: FAN(BLOWER) MOTOR
GM : GEARED MOTOR
TM : TIMER MOTOR
V.P.C. : VARIABLE POWER CONTROLLER
[ CONDITION ]
DOOR : CLOSED
TIMER : ON
V.P.C. : HIGH
RD
RD
OR
OR
SINGLE PHASE
~
ONLY
2
M
1
3
TM
FILTER ASS’Y
FUSE
L
L
NN
GN
