10
KOR-6115 WIRING DIAGRAM
POWER SUPPLY :
PRIMARY INTERLOCK SWITCH(UPPER)
TIMER SWITCH
TIMER ASS'Y
V.P.C
.
FUSE
INTERLOCK MONITOR SWITCH
HIGH VOLTAGE TRANSFORMER
H.V. CAPACITOR
H.V. DIODE
MAGNETRON
WH
LIVE RD
BK
WH
NEUTRAL WH
BK
BL
GY
GY
GY
GY
GY
GY
CL
GM
FM
SECONDARY INTERLOCK SWITCH
NOTE :
RD
: RED
WH :
WHITE
BK :
BLACK
GN : GREEN BR :
BROWN
OR :
ORANGE
BL :
BLUE
GY : GRAY GE : GREEN/YELLOW
CL
: CAVITY LAMP
FM
: FAN(BLOWER) MOTOR
GM : GEARED MOTOR TM : TIMER MOTOR V.P.C. : VARIABLE POWER CONTROLLER
[ CONDITION ] DOOR : CLOSED TIMER : ON V.P.C. : HIGH
RD
RD
OR
OR
SINGLE PHASE
~
ONLY
2
M
1
3
TM
GN
