166
Magellan TM 3200VSi
Host Transmission Buffers 2 2 2 2 2 2
Baud Rate 9600 9600 9600 9600 9600 9600
Data Bits 8 8 8 8 8 8
Stop Bits 1 1 1 1 1 1
Parity None None None None None None
Hardware Flow Control Disable Disable Disable Disable Disable Disable
Intercharacter Delay No Delay No Delay No Delay No Delay No Delay No Delay
Software Flow Control Disable Disable Disable Disable Disable Disable
Host Echo Disable Disable Disable Disable Disable Disable
Host Echo Quiet Interval 10 msec 10 msec 10 msec 10 msec 10 msec 10 msec
Signal Voltage: Normal/TTL
Normal
RS-232
Normal
RS-232
Normal
RS-232
Normal
RS-232
Normal
RS-232
Normal
RS-232
RS-232 Invert Disable Disable Disable Disable Disable Disable
Beep on ASCII BEL Enable Enable Enable Enable Enable Enable
Beep on Not on File Enable Enable Enable Enable Enable Enable
ACK NAK Options Disable Disable Disable Disable Disable Disable
ACK Character 006 006 006 006 006 006
NAK Character 021 021 021 021 021 021
Retry on ACK NAK Timeout Enable Enable Enable Enable Enable Enable
ACK NAK Timeout Value 001 001 001 001 001 001
ACK NAK Retry Count 003 003 003 003 003 003
ACK NAK Error Handling Ignore Ignore Ignore Ignore Ignore Ignore
Transmission Failure Indication Enable Enable Enable Enable Enable Enable
Single Cable RS-232 Options
RTS held
high, wait
for CTS to
be
asserted
Single Cable RS-232 Use BCC Enable
Single Cable RS-232 Use ACK/NAK Enable
Single Cable RS-232 Use STX Enable
Set Single Cable RS-232 STX Character 53
Single Cable RS-232 Use ETX Enable
FEATURE Aux RS-232
Wincor-
Nixdorf
Single
Cable
USB-OEM
Keybd
Wedge
