PARTS LIST

This list contains replaceable parts used in your heater. When ordering parts, follow the instructions

listed under Replacement Parts on page 22 of this manual.

KEY

PART NUMBER

NO.

CBT20NT

CBT20PT

CBT30NT

CBT30PT

DESCRIPTION

QTY.

1

111435-01

111435-01

111435-01

111435-01

Electronic Ignitor

1

2

107954-03CV 107954-03CV 107955-03CV 107955-03CV Front Panel

1

3

107879-02

107879-02

107879-01

107879-01

Grill Guard

1

4

098522-28

098522-11

098522-12

098522-13

Thermostat Gas Valve 1

5

107677-01

107677-01

107677-01

107677-01

Glass Retainer

2

6

098260-12

098260-12

098260-13

098260-13

Glass

1

7

**

**

**

**

Cabinet

1

8

107894-08

107894-08

107894-09

107894-09

Deflector Assembly

1

9

098271-11

098271-11

098271-11

098271-11

Ignitor Cable

1

10

098249-01

098249-01

098249-01

098249-01

ODS Pilot Nut

2

11

110803-01

110803-02

110803-01

110803-02

ODS/Pilot Assembly

1

110186-01

110186-01

110186-01

110186-01

Thermocouple Kit

1

12

103446-01

103446-01

103447-01

103447-01

Burner

1

13

099387-03

099387-03

099387-03

099387-03

3/16" Pilot Tubing

1

14

103845-06

103845-05

103845-08

103845-07

Injector

1

15

099066-02

099066-02

099066-02

099066-02

Mounting Bracket

1

16

099415-17

099415-18

099415-17

099415-18

Gas Regulator

1

17

NJF 8C

NJF 8C

NJF 8C

NJF 8C

Hex Nut

1

18

103255-02

103255-02

103255-02

103255-02

3/8" Outlet Tubing

1

19

103256-02

103256-02

103256-02

103256-02

3/8" Inlet Tubing

1

20

109303-04

109303-04

109303-03

109303-03

Baffle

1

PARTS AVAILABLE — NOT SHOWN

100642-03

100642-03

100642-03

100642-03

Hardware Assembly

1

105345-01

105345-01

105345-01

105345-01

Cable Tie

1

107888-03

107888-03

107888-03

107888-03

Control Position Label

1

109483-01

109483-01

109483-01

109483-01

Lighting Instruction

Plate

1

** Not a field replaceable part.
