PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 22 of this manual.
PART NUMBER
KEY CBN20T CBP20TK
NO. CBN20TK CBP20T CBN30T CBP30T DESCRIPTION QTY.
1 097159-04 097159-04 097159-04 097159-04 Piezo Ignitor 1
2 107954-01 107954-01 107955-01 107955-01 Front Panel 1
3 107879-02 107879-02 107879-01 107879-01 Grill Guard 1
4 098522-28 098522-11 098522-12 098522-13 Thermostat Gas Valve 1
5 107677-01 107677-01 107677-01 107677-01 Glass Retainer 2
6 098260-12 098260-12 098260-13 098260-13 Glass 1
7 ** ** ** ** Cabinet 1
8 107894-08 107894-08 107894-09 107894-09 Deflector Assembly 1
9 098271-09 098271-09 098271-09 098271-09 Ignitor Cable 1
10 098249-01 098249-01 098249-01 098249-01 ODS Pilot Nut 2
11 110803-01 110803-02 110803-01 110803-02 ODS/Pilot Assembly 1
110186-01 110186-01 110186-01 110186-01 Thermocouple Kit 1
12 103446-01 103446-01 103447-01 103447-01 Burner 1
13 099387-03 099387-03 099387-03 099387-03 3/16" Pilot Tubing 1
14 103845-06 103845-05 103845-08 103845-07 Injector 1
15 099066-02 099066-02 099066-02 099066-02 Mounting Bracket 1
16 099415-17 099415-18 099415-17 099415-18 Gas Regulator 1
17 NJF 8C NJF 8C NJF 8C NJF 8C Hex Nut 1
18 103255-02 103255-02 103255-02 103255-02 3/8" Outlet Tubing 1
19 103256-02 103256-02 103256-02 103256-02 3/8" Inlet Tubing 1
20 109303-04 109303-04 109303-03 109303-03 Baffle 1
PARTS AVAILABLE — NOT SHOWN
100642-03 100642-03 100642-03 100642-03 Hardware Assembly 1
105345-01 105345-01 105345-01 105345-01 Cable Tie 1
107888-01 107888-01 107888-01 107888-01 Control Position Label 1
109483-01 109483-01 109483-01 109483-01 Lighting Instruction Plate 1
** Not a field replaceable part.
