MACRO-CPU Hardware Reference
MACRO STATION CHARACTER DISPLAY
The Compact MACRO Station has a single hexadecimal character display on the CPU/Interface Board that
provides useful information as to the status of the station. The display can show the following values:
Value Meaning
(Blank)
Ring not active
0-8
Operation OK; value is # of motors enabled
9
(reserved for future use)
A Amplifier
fault
B
Ring break fault
C
CPU failure fault
D
Ring data error
E Loss-of-encoder
fault
F Other
failure
MACRO Station Character Display
