PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 21 of this manual.
KEY
NO.
PART NUMBER
DESCRIpTION QTY.
VYM27NR
FVFM27NR
VYM27PR
FVFM27PR
1 10466-01 10466-01 Log, Multi-Sided 1
2 1039-01 1038-01 ODS Pilot 1
3 098249-01 098249-01 ODS Nut 2
4 104592-01 104592-02 Burner Outlet Tube 1
5 098264-02 098264-02 Male Connector 1
6 111124-01 111124-01 Burner Retainer Spring 1
099056-16 099056-1 Burner Orifice Injector 1
8 104591-01 104591-01 Burner 1
9 100609-01 09938-13 Pilot Tube (Regulator to Pilot) 1
10 10381-01 10381-02 Gas Control Valve 1
11 104611-01 104611-01 Lower Bracket 1
12 098304-01 098304-01 Screw, #8 x 0.38
13 ** ** Painted Base Assy 1
14 09821-10 09821-10 Ignitor Cable 1
15 102445-01 102445-01 Piezo Ignitor 1
16 10358-02 10358-02 Plate, Switch 1
1 10384-02 10384-02 Flame Adjustment Knob 1
18 10384-01 10384-01 Off-Pilot-On Knob 1
19 M12461-26 M12461-26 Screw, Hex Slt Wsr 10-32 x 0.38 4
20 103284-02 103284-02 Wiring Harness 1
21 099998-01 099998-01 Switch 1
22 099918-02
___
Pilot Regulator 1
23 09938-15
___
Pilot Tube (Valve to Regulator) 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
1038-01 1038-01 Lighting Instructions Plate 1
100565-01 100565-01 Warning Plate Fastener 1
100639-01 100693-01 Caution Decal 1
10113-02 10113-02 Hardware Kit 1
GA6060 GA6060 Lava Rock 2
**Not a field replaceable part.
