ON/OFF SERIES (MODEL HRC100)
Hold the control button on the hand-held
remote until burner turns on. Hold the con-
trol button again until burner turns off (see
Figure 26).
To Lock
press both buttons on hand-held
remote control until light stops flashing. Hand-
held remote control is now locked. If the fire is
on it will be turned off automatically. In the
locked state, the light will not light up when
any button is pressed.
To Unlock
press both buttons together on hand-
held remote control until the light stops flashing.
The hand-held remote is now unlocked.
OPERATING HEATER
Continued
Figure 25 - Setting the Selector Switch,
Control Knob, and Flame Adjustment
Knob for Hand-Held Remote Operation
Selector Switch in Remote Position
(Optional Hand-Held Remote Control)
ON
OFF
REMOTE
O
FF
P ILOT
LO
IH
O
N
Control Knob
in On Position Flame
Adjustment Knob
THERMOSTAT SERIES (MODEL
HRC200)
The hand-held remote can be operated using
either the manual mode (MANU) or thermo-
static mode (AUTO) (see Figure 27). To select
Fahrenheit/Centigrade mode display, carefully
press the ˚C/˚F mode button with the end of a
paper clip or similar blunt object.
Figure 26 - On/Off Hand-Held Remote
Control Unit
OpTIONAL HAND-HELD
REMOTE OpERATION
All remote control accessories must be pur-
chased separately (see Accessories, page 25).
Follow instructions included with the remote
control.
NOTICE: You must light the pilot
before using the hand-held re-
mote control unit. See Lighting
Instructions on page 16.
After lighting, let pilot flame burn for about
one minute. Turn control knob to ON position.
Adjust flame adjustment knob anywhere be-
tween HI and LO. Slide the selector switch to
the REMOTE position (see Figure 25). Note:
The burner may light if hand-held remote was
on when selector switch was last turned off.
You can now turn the burner on and off with
the hand-held remote control unit.
IMPORTANT:
Do not leave the selector switch
in the REMOTE or ON position when the pilot
is not lit. This will drain the battery.
Control
Button
Indicator
Light
LOCK
MANU AUTO
ºC/ºF
TEMP
POWER
ROOM
TEMP SET
TEMP
AUTO
Turns Hand-
Held Remote
On or Off and
Allows You
to Choose
the Manual
Setting
Selects
AUTO
Mode
°C/°F Mode Button
Locks
System to
Prevent
Accidental
Ignition
Turns
Burners
On or Off
Increases or
Decreases
Room
Temperature in
AUTO Mode
Digital Display Shows
Temperature and Settings
Figure 27 - Thermostat Hand-Held
Remote Control Unit
Piezo
Ignitor
Manual Mode
1. Press the POWER and LOCK buttons togeth-
er to turn on the hand-held remote control.
2. Press the MANU button to turn on the
fireplace.
3. Press the POWER and LOCK buttons
together to turn off the fireplace.
Auto (Thermostatic) Mode
1. Press the POWER and LOCK buttons
together to turn on the hand-held remote
control.
2. Press AUTO button to select this mode.
3. Set the desired room temperature by press-
ing the TEMP + or - buttons.
4. Press the POWER and LOCK buttons
together to turn off the fireplace
