DR Power RapidFire 3.0 HP DR (June 2014 - Present) Operating Manual User Manual
Page 7
CONTACT US AT www.DRpower.com 7
Figure 1
Chapter 2: Setting Up The DR PREMIER RAPIDFIRE LOG SPLITTER
It may be helpful to familiarize yourself with the controls and features of your DR PREMIER RAPIDFIRE LOG SPLITTER as shown
in Figure 1 before beginning these procedures. If you have any questions at all, please feel free to contact us at
www.DRpower.com.
DR PREMIER RAPIDFIRE LOG SPLITTER Controls and Features
Engagement
Handle
Belt Guard
Ram
Splitting Wedge
Cradle
Frame Stand
Starter Cord
Gas Fill
Pneumatic Tires
Ignition Switch
Off
On
Electric Motor
On/Off
Switch
Circuit
Breaker
Switch
Gasoline Engine
Throttle
Lever
Choke
Lever
Safety
Interlock
Lever
Flywheel
Belt
