Serial Port
Enables or disables these serial ports (COM).
Change Settings
Selects the IO/IRQ settings for the super I/O device.
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Serial Port 4 Confi guration
Serial Port
Device Settings
Change Settings
Advanced
[Enabled]
IO=2E0h; IRQ=10;
[Auto]
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Serial Port 5 Confi guration
Serial Port
Device Settings
Change Settings
Advanced
[Enabled]
IO=2F0h; IRQ=6;
[Auto]
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save and Reset
ESC: Exit
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save and Reset
ESC: Exit
Parallel Port
Enables or disables the parallel port (LPT/LPTE).
Change Settings
Selects an optimal setting for the super IO device.
Device Mode
Changes the mode of the printer port.
Enable or Disable Parellel
Port (LPT/LPTE)
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Parallel Port Confi guration
Parallel Port
Change Settings
Device Mode
Advanced
[Enabled]
[Auto]
[STD Printer Mode]
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save and Reset
ESC: Exit
Parallel Port Configuration
Sets the parameters of the parallel port (LPT/LPTE).
