Signal
Pin#
Pin Type
Pwr Rail /Tolerance
PU/PD
Description
GPO0
A93
GPO1
B54
GPO2
B57
GPO3
B63
GPI0
A54
GPI1
A63
GPI2
A67
GPI3
A85
Signal
Pin#
Pin Type
Pwr Rail /Tolerance
PU/PD
Description
VCC_12V
A104~A109
B104~B109
C104~C109
D104~D109
Power
Primary power input: +12V nominal. All available VCC_12V pins on the connector(s) shall be used.
VCC_5V_SBY
B84~B87
Power
Standby power input: +5.0V nominal. If VCC5_SBY is used, all
available VCC_5V_SBY pins on the connector(s) shall be used. Only
used for standby and suspend functions. May be left unconnected if
these functions are not used in the system design.
VCC_RTC
A47
Power
Real-time clock circuit-power input. Nominally +3.0V.
GND
A1, A11, A21, A31, A41,
A51, A57, A60, A66, A70,
A80, A90, A96,A100, A110,
B1, B11, B21 ,B31, B41,
B51, B60, B70, B80, B90,
B100, B110, C1,C11, C21,
C31, C41, C51, C60, C70,
C76, C80, C84, C87, C90,
C93, C96, C100, C103,
C110, D1,D11,D21, D31,
D41, D51, D60, D67,
D70,D76, D80, D84, D87,
D90, D93, D96, D100,
Power
Ground - DC power and signal and AC signal return path.
All available GND connector pins shall be used and tied to Carrier
Board GND plane.
Signal
Pin#
Pin Type
Pwr Rail /Tolerance
PU/PD
Description
TYPE0#
C54
PDS
TYPE1#
C57
PDS
TYPE2#
D57
PDS
TYPE10#
A97
PDS
TYPE 10#
NC pin out R2.0
PD pin out Type 10 pull down to ground with 47K resistor
12V pin out R1.0
A carrier can detect a R1.0 Module by the presence of 12V on this pin. R2.0 Module types 1-6 will no connet this pin. Type 10 Modules
shall pull this pin to ground through a 4.7K resistor.
Module type Signal Descriptions
TYPE2# TYPE1# TYPE0#
X X X pin out Type 1
NC NC NC pin out Type 2
NC NC GND pin out Type 3 (no IDE)
NC GND NC pin out Type 4 (no PCI)
NC GND GND pin out Type 5 (no IDE, no PCI)
GND NC NC pin out Type 6 (no IDE, no PCI)
I CMOS
3.3V / 3.3V
General purpose input pins.
Power and GND Signal Descriptions
GPIO Signals Descriptions
O CMOS
3.3V / 3.3V
General purpose output pins.
