Initial use 21
devolo dLAN TV Sat 2400-CI+
3.6 Connect the dLAN TV Sat Tuner
ቢ Connect the satellite antenna to the antenna
input (LNB, multiswitch) of the dLAN TV Sat Tuner
using a coaxial cable with an F-connector.
ባ Connect the dLAN TV Sat Tuner to a
dLAN 200 AVplus adapter using the mains cable
supplied.
ቤ Insert the plug on the power pack into the socket
on the dLAN 200 AVplus adapter.
ብ Plug the dLAN 200 AVplus adapter into a free
wall socket.
If two tuners are connected, they can
be used simultaneously for recording
and viewing TV—one for recording
and the other for TV.
3.7 Connect the dLAN TV Sat 2400-
CI+ to the dLAN and the mains
supply.
ቢ Connect the dLAN TV Sat 2400-CI+ to a
dLAN 200 AVplus adapter using the mains cable
supplied.
The Ethernet plug (LAN) should only be
connected to a matching Ethernet sock-
et.
ባ Insert the hollow plug on the power pack into the
12 V DC power socket on the dLAN TV Sat 2400-
CI+.
ቤ Insert the plug on the power pack into the socket
on the dLAN 200 AVplus adapter.
ብ Then, plug the dLAN 200 AVplus adapter into a
free wall socket.
ቦ The dLAN TV Sat 2400-CI+ is now connected to
the power and dLAN networks and can communi-
cate by dLAN with the connected dLAN TV Sat
Tuner.
