Installation
1
Section 1:
Installation
1.1 Radio Receiver
Reference Drawings:
Installation; Indoor, Gen V Radio Receiver ............................................ Drawing A-203542
Installation: Outdoor- Gen V Radio Receiver ......................................... Drawing A-203543
Install Details: Outdoor Radio/Wire Switch ............................................ Drawing B-235957
Installation; Radio Bracket ..................................................................... Drawing A-267405
Installation; Outdoor Gen IV Scbds,w/ Gen V Radio ............................. Drawing A-290166
Installation- Indoor Color Smart- Gen V Receiver ................................. Drawing A-298616
Most scoreboards will have an internal mounting bracket to which the radio receiver will be
attached. Refer to the component location drawings included in the scoreboard manual for
the radio mounting location. If a bracket was not factory-installed, refer to Drawing A-267405
for bracket installation instructions.
Indoor Scoreboards
For standard indoor scoreboards, refer to Drawing A-203542.
For ColorSmart
®
color-changing digit scoreboards, refer to Drawing A-298616.
Outdoor Scoreboards
For outdoor scoreboards built after January 2007, refer to Drawing A-290166.
For outdoor scoreboards built before January 2007, refer to Drawing A-203543.
Note: For outdoor installations that have a radio/wire switch, refer to Drawing B-235957.
1.2 RC-100 Base Station
Reference Drawings:
Base Station: Outdoor Installation ......................................................... Drawing A-236394
Outdoor Installation: Radio Receiver & Base Station .......................... Drawing A-1069855
Drawing A-236394
shows the installation of an RC-100 base station for outdoor scoreboards.
For detailed RC-100 installation and setup instructions, including indoor scoreboards, refer to
the Remote Control System RC-100 All Sport Operation Manual (ED-15133), available
online a
In certain situations, it is possible that both an All Sport
®
radio receiver and an RC-100 base
station will be installed in the same outdoor scoreboard. For instance, a handheld RC-100
may be used when running practices, and then a wireless All Sport console would control the
scoreboard during the game. In these cases, refer to Drawing A-1069855.
Note: The wireless device that takes precedence is the one that the scoreboard receiver
finds active first, and it will control the scoreboard until the signal is no longer present.
