6 Basic Operation
Sport Insert Number Code
Clock/score LL-2496 01, 81
Volleyball LL-2502 02, 82
Baseball LL-2500 03, 83, 80, 87
Basketball LL-2667 21, 88
Shot clock/play clock LL-2501 04, 05, 84 ,85
Segment timer LL-2498 06
Multipurpose timer LL-2499 07
Tennis LL-2497 08
Relay board 0G-139761 09
Lap counter 0G-140230 10
Field events metric 1 0G-140229 11
Field events metric 2 0G-140229 12
Field events metric 3 0G-140229 13
Field events imperial 0G-140229 14
Gymnastics 0G-144810 15
Squash 0G-199192 16
Sport Insert Operation Concepts
A sport insert identifies the keys required for normal operation of a specific sport. In most
cases, pressing a key immediately changes the scoreboard. Keys that require entry of
additional information are marked by a dot, (such as >). This additional
information is usually a number followed by the key.
Some keys are labeled +1. Pressing one of these keys once “increments”, or increases, the
corresponding field on the scoreboard by one (such as score or period). A key with -1
“decrements”, or decreases, by one.
On most inserts, certain keys have been grouped together under the heading Home or Guest.
These keys are team keys and work the same for both teams. They affect the statistics only for
that one team. Keys not under one of these headings are game keys. They are general keys for
the progress of the game (such as period or quarter). Other keys may be grouped in a similar
way to emphasize that they work together.
2.3 Startup
Use the rocker switch on the back of the console to turn it on, then follow the LCD screens:
Display Action
The console performs a self-test when it is powered on. During
the self-test, a message displays the version of the standard
software loaded in the console.
V = version number and revision number
ED = standard software number
AS-1600 VX.X.X
ED-12480
