11

© 2 0 0 3 d i r e c t e d e l e c t r o n i c s , i n c .

Number Icons

When either of the channel 2 or 3 outputs is activated the appro-

priate icon will be displayed for five seconds.

rre

em

mo

otte

e o

op

pe

erra

attiio

on

n a

an

nd

d p

prro

og

grra

am

m--

m

miin

ng

g iin

nssttrru

uc

cttiio

on

nss

This security system operates at 434 MHz and incorporates

Directed’s proprietary XHF2 out-board Responder Technology

remote control. The high frequency combined with Binary Data

communication achieves superior range with two-way commu-

nication.

system signal paging features

A page is the signal the control module sends to the remote

control as confirmation of receipt of a command or alarm system

status.

When the remote control receives a page it will generate a page

notification to the user (notifications are audible beeps or remote

vibration) and the LCD Icons will display the current system

status.

Command Page

When a command (arm/disarm, remote start, or auxiliary

channel) from the remote control is sent and received, the system

will send a command page back to confirm receipt.
