Product Reference Guide
F-1
Appendix F
Handheld Data Format
Requirements
This appendix provides application notes to describe the general format of
data that can be accepted by the scanner through the auxilliary port as
transmitted from a handheld scanner.
Handheld Data Format Requirements General
•
9600 bps, 8 data bits, 1 stop bit, no parity.
•
RTS is used to "bracket" the data received from the handheld: RTS
must be asserted high during data transmission, and de-asserted
after label transmission is complete. No other flow control mecha-
nisms are required or supported.
•
Symbologies requiring fixed lengths (UPC/EAN) will enforce length
requirements for validation of the label.
•
Handheld will be required to transmit start and stop characters for
Codabar and Code 39 labels.
•
Appropriate industrial length requirements will be enforced (if con-
figured) for validation of the label.
•
Maximum label lengths will be enforced for label validation (i.e.
labels longer than the maximum label size will not be validated).
•
Standard Datalogic formats generally use a single prefix character.
The specific formats are provided below.
