IBM USB Cable Pinout
Product Reference Guide
B-5
IBM USB Cable Pinout
Scanner and Scale
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table B-4IBM USB Cable Pinouts
PIN #
FUNCTION
DESCRIPTION
1
N/C
No Connection
2
N/C
No Connection
3
N/C
No Connection
4
USB D-
USB D-
5
N/C
No Connection
6
USB D+
USB D+
7
N/C
No Connection
8
+5V out
+5V out
9
GND
Signal Ground
10
N/C
No Connection
