Page 410
B-4
Magellan
®
9500
IBM Cable Pinout
Scanner and Scale
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table B-3IBM Cable Pinouts
PIN #
FUNCTION
DESCRIPTION
1
N/C
No Connection
2
N/C
No Connection
3
N/C
No Connection
4
LINEB
Line B
5
N/C
No Connection
6
LINEA
Line A
7
N/C
No Connection
8
+5V out
+5V out
9
GND
Signal Ground
10
N/C
No Connection
