B-2
Magellan ® 9500
RS-232 Cable Pinout
Scanner
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table B-1RS-232 Cable Pinouts
PIN # FUNCTION DESCRIPTION
1 N/C No Connection
2 CTS in Clear To Send (input)
3 N/C No Connection
4 RTS out Request To Send (output)
5 RxD in Receive Data (Input)
6 TxD out Transmit Data (output)
7 N/C No Connection
8 +5V out +5V out
9 GND Signal Ground
10 N/C No Connection
