System Component Descriptions
Echo Transmitter
The Echo Transmitter connects to the SIRIUS indoor/
outdoor or outdoor home antenna and wirelessly
broadcasts the SIRIUS signal throughout the home.
It can be placed on a flat surface or wall mounted
vertically using two screws and the mounting slots
on the base of the unit.
The Echo Transmitter has Power and Antenna con-
nections on the rear of the unit, and three green
LEDS on the front, labeled "SIGNAL" "POWER" and
"ANTENNA" respectively from left to right. It also
has a black plastic antenna on the side that can
swivel up and down.
The “POWER” LED lights up when the unit is prop-
erly connected and powered by the AC Adapter. The
“ANTENNA” LED lights up when the SIRIUS home
antenna is properly connected to the Echo Transmit-
ter. The “SIGNAL” LED lights up when the SIRIUS
home antenna is receiving a good strong SIRIUS
signal that can be broadcasted by the Echo Trans-
mitter. For proper operation of the Echo Transmitter,
all three LEDs need to be lit up. The black plastic
antenna on the side needs to be swiveled up in an
upright vertical position, so that it is always pointing
straight up, regardless if the unit is placed on a flat
surface or mounted to a wall.
