VIBRATO
The DigiTech Vibrato effect modulates the pitch of the incoming signal at an even rate.
Parameters include:
Speed
Adjusts the rate (Speed) at which the pitch modulates. Ranges from 0 to 99.
Depth
Adjusts the intensity (Depth) of the modulating pitch. Ranges from 0 to 99.
ROTARy SPEAkER
The Rotary Speaker emulates a device that included a spinning horn and woofer. The
rotation of these two speakers produced an interesting combination of the sound panning
from side to side. This produced a slight pitch change due to the speed of the sound
coming towards, and then going away from the listener. Parameters include:
Speed
Adjusts the rate (Speed) of the spinning speakers. Ranges from 0 to 99.
Intensity
Controls the intensity of the effect. Ranges from 0 to 99.
Doppler
Controls the Pitch Shift effect that is the ratio between the horn and the rotor posi-
tions. Ranges from 0 to 99.
Crossover
Selects the crossover frequency between the horn and rotor. Ranges from 0 (200 Hz)
to 99 (1600 Hz).
VIBROPAN.
A vibrato is an effect that modulates the pitch of the incoming signal. This takes the whole
signal slightly in and out of tune at a steady pace. The DigiTech
® VibroPan also incorpo-
rates an automatic panner with the vibrato effect that creates a lush chorus-like sound.
Parameters include:
Speed
Adjusts how fast the signal is being modulated.
Depth
Adjusts the amount of pitch change.
Vibrato/Pan
Adjusts the amount of panning incorporated with the vibrato effect. When set at 0, this
effect is a standard vibrato. As the parameter is turned up, the phase difference of the
vibrato signal sent to the two channels is changed until a full stereo image is obtained at
99.
Waveform
Selects a waveform: Triangle, Sine, or Square.
