www.desatech.com 116658-01C 33
Key
NO. PART NO.
DeSCRIPTION QTy.
1 ** Outer Casing Top 1
** Baffle 1
3 ** Outer Casing 1
4 10481-0BR Firebox Hood 1
5 ** Firebox Top 1
6 ** Firebox Wrapper 1
7 ** Outer Base 1
8 10635-0 Front Left and Right Sides
1030-05 Extruded Louver
10 08304-01 Screw, PPH AB 10-16 x .38 1
11 M1008- Screw, SLTD HWH TPG 6-3 x 0.38 4
1 104313-01 Right Pin Hinge 1
13 104313-0 Left Pin Hinge 1
14 030-0 Screw, HWH SHLDR AB 10 x 0.63 14
15 111038-0 Remote/Blower Bracket 1
16 M11084-6 Screw, HEH AB 10-16 x 0.38 35
17 111633-01 Box Cover 1
18 11100-01 Support Bracket 1
1 11647-01 Brick Liner Kit 1
0 114408-01 Retainer
1 105440-01 Screen Assembly 1
10345-03 Screen Rod
** Not a field replaceable part
paRTs lisT
FIREBOx MODELS
CDCFNRA AND CDCFPRA
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 33 of this manual.
