Caple CR9105 - Manual (Page 32)

32
Burners
They can be removed and washed with soapy water only.
They will remain always perfect if cleaned with products used for silverware.
After cleaning or wash, check that burner-caps and burner-heads are dry before plac-
ing them in the respective housings.
Note: To avoid damage to the electric ignition do not use it when the burners are
not in place.
Fig. 8.2 Fig. 8.1
S
F
C
T
Correct replacement of the burners
It is very important to check that the burner flame distributor F and the cap C has
been correctly positioned (see figs. 8.1, 8.2) - failure to do so can cause a poor burn-
er flame and/or damage to the burner and hob.
Check that the electrode S (figs. 8.1, 8.3) is always clean to ensure trouble-free
sparking.
Check that the probe T (figs. 8.1, 8.3) next to each burner is always clean to ensure
correct operation of the safety valves.
Both the probe and ignition plug must be very carefully cleaned.
