Caple CAFF40 User Manual

Page 5

Start to Use

We suggest you get a

good knowledge of all the safety precautions and make sure that your

refrigerator has been placed properly in its final position before using.

Unpacking

Please install the decorative cover on the bottom beam of your refrigerator after unpacking and
adjust the front leveling legs to level your refrigerator.

Connecting Your Refrigerator to the Power Supply

Your refrigerator will enter the ex-factory default state after connecting to the power supply
and it will display

a target

temperature for the refrigerator compartment and freezer

compartment.

Modes of Your Refrigerator

You can set your refrigerator in either of the following two ways:
(1)

Smart mode: we suggest you

this mode if you have no special requirements.

select

Your refrigerator will work automatically after you chose this mode.
(2)

Manual mode: You can set the temperature by pressing the temperature adjustment key.

Adding Food To

Your Refrigerator

After the appliance has been switched on for a period of time it should have cooled to the set
temperature (about 3 hours in summer).Once this has been done you can add the food.

Tips: The interior temperature may require a certain period of time to reach balance if
the setting temperature is changed or other food is put into the refrigerator. Such a
period of time depends on the change to the set temperature, the surrounding
temperature, opening frequency, the amount of the stored food and etc.

Refrigerator compartment
Though the temperature-

device

keep most of

adjustment

you can

the refrigerator compartment at an average temperature around
2~8, it fails to preserve the freshness of food for long. As a
result, the refrigerator compartment can be used only for short-
term storage.
l

Use of turnover beam

Please keep strictly to the warnings on the label of the turnover
beam. It is a normal phenomenon that the surface of the
turnover beam is hot. Dews on the surface are also normal in
summer or when the surrounding environment is wet. What you
need to do is to

wipe them away with a clean cloth.

Use of water tank

Add pure water or mineral water into the tank other than tap
water (don't put juice, milk or other drinks into the water tank;
otherwise, the pipe may be blocked). Please fill water as soon
as possible if the water level in the tank is low. Generally, the
water filter blocks in the tank

be changed annually, as the

should

case may be.
l

Adjustment of cantilever rack

The cantilever rack could be adjusted to the proper height as
required by food. Please adjust the cantilever rack by following
the arrows as shown in the diagram. Raise it upward first and
then take it out by tilting it upward. During installation, put the
upper end of the fixed leg into one of the upper slots on the
supporting iron first and then put the lower end of the fixed leg
into the third slot on the lower part of the supporting iron.
l

Height adjustment and cleaning of door-mounted bottle

rack
Raise the bottle rack in direction 1. hold it with both hands
and take it out in direction 2. After cleaning, you can install
the rack in the reverse order and you can also adjust the height
of the rack.

Slot

Adjustment of cantilever rack

Correct Use for Your Refrigerator

Food suggested to store in refrigerator compartment

(1)

Cooked food, cans, milk, etc.

(2)

Snack food, food subject to tainting, dairy

products

(3)

Cooked cold meat, sausage

(4)

Fruit, vegetables

(5)

Eggs, butter, cheese

(6)

Cans, seasoning

(7)

Drinks, other bottled food

Freezer compartment

The temperature in the freezer compartment is very low so it

the freshness of

preserves

food

for

. Foods that are to be stored for

could be put in this

long periods of time.

a long time

compartment but not exceed the storage period specified on the packaging of each

of food.

type

NOTE:

You can take out the drawers of the freezer compartment to increase its

capacity and store more food.

Food suggested to store in freezer compartment

(1)

The upper drawer of the freezer could be used to store fish, meat, ice-cream and etc.

(2)

Japanese-style ice maker is used to make ice

(3)

Ice storage box is used to store the ice

(4)

The lower drawer of the freezer is used to store fish, meat and packaged poultry meat.

NOTE:

Don't touch the freezer tray directly with hands to avoid injury caused

by the very low temperature.

Removing

and installing the lower freezer drawer

(1)

Pull out the lower freezer drawer first.

(2)

Take out the two fixed screws from the partition plate of the lower freezer drawer with screw
driver and then take off the partition plate.

(3)

Take off the rear stopper for the lower drawer as shown by Fig. A.

(4)

Take out the lower drawer body with force as directed by the arrows in Fig. B.

(5)

The installation of the lower drawer body is conducted in the reverse order. You should
install the lower drawer body first and then install the rear stopper for the lower drawer as
shown in Fig. C. Finally, both sides of the drawer shall be connected to the position shown
by the arrows respectively.

(6)

The partition plate is installed into the corresponding slots and then is fixed with screws.
The position of the partition plate for the lower drawer could be adjusted according to your
preference.

Advice: Don't remove the lower freezer drawer if not necessary.

Correct Use for Your Refrigerator

Upper end of
fixed leg

Lower end of
fixed leg

Adjustment of
door-mounted bottle rack

Rear stopper for the lower drawer

Lower drawer body

lower drawer

Partition plate for the

Insert into the edge

Align with the slot

Align with
the slot

Positioning hole

for the partition

plate
