LB-HDMI/DE User’s Manual
Link Bridge TM HDMI Audio De-embedder System
Broadata Technical Support, [email protected] 5
1.0 PRODUCT DESCRIPTION
The LB-HDMI/DE-CH Audio De-embedder has been specifically designed
for mounting in the LB-CH chassis (Figure 1), it allows the user to extract
audio signals from an HDMI source. When connecting an HDMI signal
to a TV or display the best audio is not always available, or in the case
of a PC monitor, there is no audio at all available. Thus, with the
LB-HDMI/DE unit the user can take the original HDMI audio signal and
convert it to digital optical or analog Stereo (L/R) audio. This means that
there is an audio output available to external speakers or to audio
processing hardware, or to extend the audio signal pathway.
Features
• Compliant with HDMI, HDCP 1.2 and DVI 1.0
• Supports HDMI audio sampling rates up to 192 kHz
• Supports Optical S/PDIF sampling rates up to 48 kHz
• Supports high-bit-rate (HBR) audio
• No HDMI output connection is required to receive audio at the
analog and optical outputs
• Supports EDID management for audio formats, can switch
among built-in EDID (LPCM 2CH/Bitstream) and external EDID
(TV)
• Supports 3D signal
Package Contents
1 LB-HDMI/DE Audio De-embedder
1 Power Adaptor, 12VDC
1 User Manual
