LB-HDMI/DE User’s Manual
Link Bridge TM HDMI Audio De-embedder System
Broadata Technical Support, [email protected] 11
5.0 SPECIFICATIONS
Input Port 1 x HDMI
HDMI Audio Sampling Rate Up to 192 kHz
Optical Audio Sampling Rate Up to 48 kHz
Output Ports 1×HDMI, 1×Optical,1×L/R
HDMI Audio Format LPCM 2/5.1/7.1CH, Dolby 5.1, DTS
5.1, DD+, D- TrueHD & DTS-HD
Optical Audio Format LPCM 2CH, Dolby 5.1 & DTS 5.1
L/R Audio Format Analog Stereo 2CH
Dimensions 90.7 mm (W)×85.8 mm (D)
×34 mm (H)
Operating Temperature 0 ÚC~40 ÚC/32 ÚF~104 ÚF
Storage Temperature “20 ÚC~60 ÚC/”4 ÚF~140ÚF
Relative Humidity 20 ~ 90 % RH (non-condensing)
Chassis material Metal
Box Color Black
Operating Temperature 0 o ~ 50 o
Relative Humidity 0 ~ 95% RH (non-condensing)
Power Supply 110 – 240v AC 50/60 Hz, 12v @
1.5 A DC
Power Supply V / A DC (US/EU standards,
CE/FCC/UL certified) or 5VDC
Linear Power Adapter (US/EU
Standards, CE/FCC/UL certified)
