BCI LBS-08x08 User’s Manual
Link Bridge TM Universal 8x8 Optical/DVI/HDMI Matrix Switch
Broadata Technical Support, [email protected] 5
1.0 PRODUCT DESCRIPTION
The LBS Series is a high performance Link Bridge TM Universal Matrix
Switcher System that provides up to 8x8 video switching for HDMI/DVI
signals. It supports 12-bit deep color resolutions up to 1080p and
1920x1200@60Hz with multi-channel digital audio, such as LPCM 7.1CH,
Dolby TrueHD, Dolby Digital Plus and DTS-HD. Standard versions of the
LBS support all optical switching, or hybrid optical/electrical switching,
for HDMI/DVI signals. When configured for optical switching, only one
fiber is required per input or output port. In addition, the distance between
the switch and HDMI/DVI devices can be up to 400m when connected
by fiber cable. The LBS comes in a 2-RU packaging design.
The LBS supports jitter-free, high-quality HDMI/DVI Display with several
EDID functions for independent display resolution at per-port basis. Types
of switching control available: manual control panel, standard
RS-232, or Ethernet Web GUI and Telnet control.
