BCI LBS-08x08 User’s Manual
Link Bridge
TM Universal 8x8 Optical/DVI/HDMI Matrix Switch
Broadata Technical Support, (800) 214-0222 14
4.0 SPECIFICATIONS
Matrix Switch
Array Size Up to 8x8
EDID Control Built-in Internal Standard EDID
HDMI/DVI Ports*
Signal Single Link DVI 1.1, HDMI 1.3
Resolution Up to 1080p or 1920x1200@60Hz
Connector DVI or HDMI Female Plugs
Protocol EDID/DDC and HDCP Capable
Fiber Ports
Fiber Type Multimode 50um or 62.5um
Connector SC
Protocol EDID/DDC and HDCP Capable
Control
Manual Panel Button
RS-232 DB-9, 19.2 kb/s
Ethernet 10/100Base-T for Web
Browser, Telnet
Physical
Dimension (H x W x D) 3.5” x 19.0” x 13”,
Including chassis handle
