PARTS LIST
NO.
Description
QTY
NO.
Description
QTY
FusionGS-1
Frame
1
FusionGS-42
Cross umbrella screw
2
FusionGS-2
Handlebar
1
FusionGS-43
Cross countersunk bolt
2
FusionGS-3
Handlebar post
1
FusionGS-44
Self-tapping screw
8
FusionGS-4
Pop pin
3
FusionGS-45
Bearing 6004
2
FusionGS-5
Adjustment knob
1
FusionGS-46
Chain
1
FusionGS-6
Cap of handlebar post
2
FusionGS-47
Axle
1
FusionGS-7
Plastic sheath of inner pipe
2
FusionGS-48
Nut cover
2
FusionGS-8
Seat post
1
FusionGS-49
Hexagon flange nut
2
FusionGS-9
Seat slider
1
FusionGS-50
Left pedal
1
FusionGS-10
Seat slider caps
2
FusionGS-51
Right pedal
1
FusionGS-11
Seat post sheath
1
FusionGS-52
Pedal strap
2
FusionGS-12
Seat
1
FusionGS-53
Pedal cage
2
FusionGS-13
Resistance knob
1
FusionGS-54
C-shaped snap ring
2
FusionGS-14
Brake pole
1
FusionGS-55
Wave washer
1
FusionGS-15
Plastic sleeve tube
1
FusionGS-56
Left crank
1
FusionGS-16
Rubber washer
1
FusionGS-57
Right crank + Chain Wheel
1
FusionGS-17
Brake adjustment nut
1
FusionGS-58
Small chainwheel
1
FusionGS-18
Hex nut
1
FusionGS-59
Locknut
2
FusionGS-19
Cap nut
1
FusionGS-60
Nylon nut
1
FusionGS-20
Brake pad
1
FusionGS-61
Chain adjuster
2
FusionGS-21
Brake pad holder
1
FusionGS-62
Hex bolt
2
FusionGS-22
Brake bracket
1
FusionGS-63
Hex screw
1
FusionGS-23
Inner hexagon column bolt
2
FusionGS-64
Bearing 6ø8
4
FusionGS-24
Bigger washer
2
FusionGS-65
Front stabilizer
1
FusionGS-25
Cross umbrella screw
2
FusionGS-66
Back stabilizer
1
FusionGS-26
Flywheel
1
FusionGS-67
Foot leveler
4
FusionGS-27
Flange nut
1
FusionGS-68
Hex nut
4
FusionGS-28
Bearing 6001
2
FusionGS-69
Stabilizer cap
4
FusionGS-29
Flywheel spindle
1
FusionGS-70
Flat washer
4
FusionGS-30
Bushing
1
FusionGS-71
Hex round screw
4
FusionGS-31
Flat washer
2
FusionGS-72
Water bottle holder
1
FusionGS-32
Hexagon thin nut
2
FusionGS-73
Cross umbrella screw
2
FusionGS-33
Cap nut
2
FusionGS-74
Flat washer
2
FusionGS-34
Large washer
1
FusionGS-75
Computer
1
FusionGS-35
Chain cover a
1
FusionGS-76
Computer bracket
1
FusionGS-36
Chain cover b
1
FusionGS-77
Cross umbrella screw
2
FusionGS-37
Front cover
1
FusionGS-38
Bracket nut
1
FusionGS-39
Rubber washer
2
FusionGS-40
Chain cover plastic washer
2
FusionGS-41
Flat washer
2
