14
STEP 3: Assemble the Handlebar Post
Loosen the Pop Pin and pull out (4), and slide the
Handlebar Post (3) into the Handlebar Post Housing on
the Main Frame (1), Make sure the Pop Pin (4) is seated
in the appropriate hole on the Handlebar Post (3), then
tighten the Pop Pin (4) to secure.
STEP 4: Attach the Handlebar
Attach the Handlebar (2) to the Handlebar Post
(3) to desired adjustable position. Tighten using
Adjustment Knob (5) and Large Washer (34).
STEP 5: Installing the Seat Post
Loosen the Pop Pin and pull out (4), slide the Seat
Post (8) into the Seat Post Housing on the Main
Frame (1) and seat at the desired position. Release
the Pop Pin (4) and make sure the Seat Post (8) is
seated in a pre-drilled hole, then tighten the Pop Pin
(4) to secure.
