PARTS LIST
To order replacement parts: provide your customer service representative with the product model
number and the part number located on the Parts List below, along with the quantity you require.
No.
Description
Qty
No. Description
Qty
1
Computer assembly
1
111
Base H-GK
1
2
Computer upper cover
1
113 Foot pad (black)
4
3
Nut
12
114 Washer drilling philips self tapping screw
8
4
Tablet shelf
1
115 Wheel 50
2
5
Round head philips screw
2
116 Truss hex screw K-288
2
6
Nut (black)
2
117 Nut M10xP1.5
8
7
Wireless Bluetooth
1
118 Flex tube welding
1
8
Computer (7”LCD show contain iron board+BT function)
1
119 Pedal
1
9
Safety switch set (haili) wire length 650mm
1
120 Inner cap
1
10
Key board 20 key
1
121 Truss philips screw
1
17
Computer panel sticker (for treadmail)
1
122 Fixed position screw M4xP0.7x10
1
26
Round head self tapping screw 3x8
30
123 Flex tube
1
27
Round head self tapping screw 3x8
6
124 Flex outer cover
1
28
Round head self tapping screw 4x16
21
127 Nut M5xP0.8
1
29
Control wire(up)
1
132 Frame GH 20”x54”
1
31
Wireless heartbeat receiver wire 400mm
1
133 Power wire socket SC-8-3C
1
32
Keyboard connector wire
1
134 Power switch R595KDT-T2FS
1
34
BT connector wire
1
135 Sensor round pillar (6.5x30) wire length 1050mm
1
35
Control wire(lower)
1
136 Sensor fixed base
1
37
Handle pulse board(wire length 260mm)
1
137 Power wire (for theadmail)
1
38
Computer shelf welding FA-GH(with handrail switch)
1
138 Fixed pad -30 mm (black)
6
43
Truss phillips screw
1
139 Motor cover front fixed piece
2
44
USB charging board
1
140 Motor cover side fixed piece
2
46
MP3 USB power wire
2
141 Front pedal(left ) GL
1
47
Single square trumpet (2X3W)+wire
2
142 Front pedal(right) GL
1
48
Sound source board
1
144 Middle pedal GH
2
49
MP3 sound source wire(M to M)
1
145 Rear pedal(left) 5T-GH
1
50
Truss hex screw K-299
8
146 Rear pedal(right) 5T-GH
1
51
CKS hex screw M8XP1.25X120
1
149 Flat cap
2
52
CKS hex screw M10xP1.5x20
4
151 Compression spring
1
53
Truss phillips screw M5xP0.8x15
5
154 Running board
1
54
Handlebar set up tube welding (left) FA-GH
1
155 Running board bracket
2
55
Handlebar set up tube welding (right) FA-GH
1
157 Foam grip 1210mmx35mmx1.5t single side sticker black
2
57
25x25x0.9tx 369 Flex inner tube
1
158 Counter sunk hex screw M8xP1.25x30
6
58
Motor cover
1
159 Counter sunk hex screw M8xP1.25x35
2
60
Motor lower cover(front)
1
161 Washer drilling philips screw ∮4x12
16
60A Motor lower cover(rear)
1
164 Overload protection switch 88-13-SR13
1
61
Girding 3.6x163mm black
2
169 Wire fixed knob UC-0.5
3
62
Air pressure stick
1
171 Terminal wire (white) 14AWGx90x2T
1
63
Truss hex screw M8xP1.25x45
1
172 Terminal wire (black) 14AWGx90x2T
2
64
CKS hex screw SK-439A
4
173 Terminal wire (white) 14AWGx170x2T
1
65
Incline base welding
1
174 Terminal wire (black) 14AWGx170x2T
1
67
Truss hex screw M8xP1.25x50
1
175 Terminal wire (yellow green)-14AWGx130mmx1T1R
1
69
Flat cap 15x30x2.0t
2
179 Belt (1500mm)
1
70
Incline base
2
180 Safety Key
1
71
R PIN
2
184 L shaped hex wrench 6x80x80mm
1
76
Washer 8x19x3.0t
1
185 Silicon DC-1000 30C.C.
1
77
Spring washer M10
4
188 Bolt
1
78
D.C Motor (1.75HP-110V)
1
226 Truss hex screw M8xP1.25x15
2
81
Truss phillips screw 4x64
12
227 Washer Φ8xΦ19x2.0t
2
82
Truss phillips screw 4x10
8
228 Truss hex screw M8xP1.25x40
2
82A Truss phillips screw ψ4x12
11
229 Plum blossom wrench
1
83
Truss hex screw M8xP1.25x35
2
230 L shaped hex wrench 5x30x120mm
1
85
Flat washer 10x20x3.0t
4
231 Handle pulse plastic base
4
86
Motor fixed slice
1
232 Handle pulse sensor piece
4
87
CKS hex screw M8xP1.25x10
2
233 Two side sticker 25mmx75mmx0.3t
4
88
Spring washer M8
2
234 Handle pulse sensor wire
1
90
Hex nut M8xP1.25
1
235 Round phillips screw M3xP0.5x30
4
91
Controller 1.0~1.25HP_110V
1
236 Hex nut M3xP0.5
4
93
Wheel (black)
2
237 Flat cap φ1-1/4”
2
99
Belt
1
238 Oval cap 36x66
2
100
Running belt 500x2910x1.4t
1
239 HDR grip
2
101
Front roller (60) TMT bearing
1
240 Handle switch plastic
2
102
CKS hex screw M8xP1.25x55
3
241 Handle switch +wire
2
103
Washer 8x16x1.5t
3
242 Counter sunk phillips screw 3x45
4
104
Rear roller (60) TMT bearing
1
243 Handle switch sticker-speed
1
107
Rear decorative cover(left) 5T-GH
1
244 Handle switch sticker-angle
1
108
Rear decorative cover(right) 5T-GH
1
245 Fan
1
109
Round head philips screw M4xP0.7x20
2
246 Truss phillips self tapping screw Φ4x32
4
110
Washer philips screw M4xP0.7x16
4
247 Computer inner box 7”
1
