Chapter: Mechanical Drawing

PCB: Pin1 Dimensions

page 60

Beckhoff New Automation Technology CB4050

7.2 PCB: Pin1 Dimensions

N

OTE

All dimensions are in mil (1 mil = 0,0254 mm)
