PRELIMINARY DATABRIEF
DB_DNT12_06252007

Delphi series DNT12 Non-Isolated Point of Load

DC/DC Power Modules: 8.3~14Vin, 0.75~5.5Vo, 3A/5A

The Delphi series

DNT12, 8.3V~14V input, single output, non-isolated point of

load DC/DC converters are the latest offering from a world leader in power

systems technology and manufacturing - Delta Electronics, Inc. The DNT12

series provides a programmable output voltage from 0.75V to 5.5V using an

external resistor. This product family is available in a surface mount or SIP

package and provides up to 3A or 5A of current in an industry standard

footprint. With creative design technology and optimization of component

placement, these converters possess outstanding electrical and thermal

performance and extremely high reliability under highly stressful operating

conditions.

APPLICATIONS

Telecom/DataCom

Distributed power architectures

Servers and workstations

LAN/WAN applications

Data processing applications

OPTIONS

Positve On/Off logic

Surface mount and SIP packages

FEATURES

High Efficiency: 92.5% @ 12Vin, 5V/3A out

Small size and low profile:

0.80” x 0.45” x 0.27” (SMD)

0.90” x 0.40” x 0.25” (SIP)

Standard footprint and pinout

Resistor-based trim

Output voltage programmable from

0.75Vdc to 5.5Vdc via external resistors

Pre-bias startup

No minimum load required

Fixed frequency operation

Input UVLO, Output OTP, OCP

Remote ON/OFF

ISO 9001, TL 9000, ISO 14001, QS9000,

OHSAS18001 certified manufacturing facility

UL/cUL 60950 (US & Canada) Recognized,

and TUV (EN60950) - pending

CE mark meets 73/23/EEC and 93/68/EEC -

pending
