Delta Electronics SMT Power Inductor SHCN 660 User Manual

Smt power inductor, Shcn 660 type, Electrical characteristics

background image

25 , 100KHz, 1V

O

C

Electrical Characteristics :

RoHS compliant.
High current handling capability in the smallest footprint & profile.
Self-leads, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized
inductors are available to meet your exact requirements.

Mechanical Dimension :

Features

SMT Power Inductor

SHCN 660 Type

RECOMMENDED PAD PATTERNS

UNIT : mm/inch
A = 4.10 / 0.161
B = 5.90 / 0.232 Max.
C = 6.00 / 0.236 Max.
D = 5.80 / 0.228 Max.
E = 3.85 / 0.152
F = 2.00 / 0.079
G = 5.70 / 0.224
H = 5.70 / 0.224

B

A

C

D

E

F

G

H

Irms

(Adc)

Isat

(Adc)

2

1

3

PART NO.

DCR

(m )

MAX

Lo

(uH)

1. Tolerance of inductance is 15%.
2. Isat is the DC current which cause the inductance drop less than
20% of its nominal inductance without current.
3. Irms is the DC current which cause the surface temperature of the

O

part increase less than 45

C.

O

O

4. Operating temperature : -20

C

to 105

C

( including self-temperature rise ).

SHCN660-R22

0.22

1.8

28

27

SHCN660-0R4

0.40

3.5

23

20

SHCN660-0R5

0.50

4.0

18

17

SHCN660-1R2

1.20

7.0

10

10

DELTA ELECTRONICS, INC.

(TAOYUAN PLANT CPBG)

252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com

140

SHCN660 series (Lvs.I)

0

300

600

900

1200

1500

0

2

4

6

8

10 12 14 16 18 20 22 24 26 28 30 32

BIAS (A)

IN

D

U

C

T

A

N

C

E

(n

H

)

1R2

0R5

0R4

R 2 2
