Mechanical drawing, Thermal cureves, Vertical – Delta Electronics Delphi ND Series User Manual
Page 11
DS_ND12S10A_07172008
11
MECHANICAL DRAWING
VERTICAL
THERMAL CUREVES
ND12S0A0V50(standard) Output Current vs. Ambient Temperature and Air Velocity
@Vin=12V Vout=3.3V (Through PCB Orientation)
0
5
10
15
20
25
30
35
40
45
50
55
25
30
35
40
45
50
55
60
65
70
75
80
85
Natural
Convection
Output Current (A)
Ambient Temperature (℃)
100LFM
200LFM
400LFM
300LFM
Figure 35:
Output current vs. ambient temperature and air
velocity@ Vin=12V, Vout=3.3V(Through PCB Orientation)
