9252000895 Rev C
BE1-50/51B-231 Time Characteristic Curves
A-1
APPENDIX A • TIME CHARACTERISTIC CURVES
Time Characteristic Curves
Figures A-1 through A-14 illustrate the time characteristic curves that are programmed into the nonvolatile
memory of this relay.
Figure A-1. Time Characteristic Curve, S-Short Inverse
(SW3-3 OFF, Similar to ABB CO-2)
