Front view side view – Basler Electric BE1-50/51B User Manual
Page 36
4-2
BE1-50/51B Installation
9252000991 Rev R
Figure 4-2. Outline Dimensions, A1 Case (Semi-Flush Mount)
Figure 4-3. Panel Drilling Diagram, S1 Case (Semi-Flush Mount)
FRONT VIEW
SIDE VIEW
(157.2)
6.19
(19.1)
.75
MOUNTING PANEL
D2750-23
3.16
(80.2)
(80.2)
3.16
.31
(7.9)
(168.91)
6.65
(192.28)
7.57
(60.96)
2.40
(49.53)
1.95
(55.75)
2.195
