26
LUBRICATING CHAIN
1. Shut off the engine
2. Add light amounts of machine oil or chain lube to the driving chain. (Too
much machine oil or chain lube may cause splattering to occur.)
Attention:
The chain should be replaced when the adjusting limit has reached it’s maximum.
ADJUSTMENT OF CHAIN
1. When chain adjustment is needed, loosen rear axle bolt .
2. Turn the chain adjusting nuts on the left and right sides to adjust the tension
of the chain and to align the marking of the chain adjuster with the engraved
lines in the similar position on both sides.
3. Tighten rear axle bolt by a torque of 50-60Nm (37-44 ft.lb.).
4. Repetitively check the tension of the chain.
15-20mm
1/2” - 3/4”
Chain adjusting nuts
Rear axle bolt
MAINTENANCE
