PARTS LIST
Models VC42NE, VC42PE, VVC42NE and VVC42PE
PARTS LIST
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 28 of this manual.
REFRACTORY BRICK PANELS
VC42NE
VVC42NE
VC42NHE VVC42NHE
VC42PE
VVC42PE
VC42PHE VVC42PHE DESCRIPTION
QTY
111299-02
111299-01
111302-02
111302-01
Left Refractory Brick Panel
1
111297-02
111297-01
111300-02
111300-01
Rear Refractory Brick Panel
1
111298-02
111298-01
111301-02
111301-01
Right Refractory Brick Panel
1
** Part not available for field replacement.
KEY PART
NO.
NUMBER
DESCRIPTION
QTY.
1
**
Firebox Assembly
1
2
**
Face Weldment
1
3
108328-01
Door Assembly
1
108328-02
Door Assembly (V Models Only)
1
4
108331-01
Top Louver Assembly
1
5
108331-02
Bottom Louver Assembly
1
6
**
Fireplace Top
1
7
**
Fireplace Top Insulation
1
8
**
Fireplace Surround
1
9
109082-01
Heat Shield
1
10
116216-01
Log Set
1
11
116338-01
Burner Log Right
1
12
116339-01
Burner Log Left
1
13
See Below
Left Refractory Brick Panel
1
14
See Below
Rear Refractory Brick Panel
1
15
See Below
Right Refractory Brick Panel
1
16
108445-01
Screen Rod
1
17
108740-01
Screen
2
18
11418
Push-On Nut
2
19
14123
Strain Relief
1
20
21171
Gas Knock-Out Cover
2
21
24353
Handy Box Assembly
1
22
24460
Gas Conduit Assembly
1
23
116211-03
Burner Assembly (Natural Gas)(See page 34)
1
116211-04
Burner Assembly (Propane/LP Gas)(See page 34)
1
24
116375-01
Plenum
1
PARTS AVAILABLE - NOT SHOWN
25487
Lava Rock/Bag Assy
1
27253
Notice Label
1
55240
Vent Label
1
116388-01
Grate Finial
1
