Dayton Operating Instructions and Parts Manual 3WY47, 3W735B, 3W736C, 3WY44, 3TE27A, 3WY45, and 3WY46
12
Dayton Professional-Duty
Electric Generators ®
(*) Always use starting watts (maximum VA), not running watts, when figuring correct electrical load.
(†) Motors of higher horsepower are not generally used.
Please check with appliance manufacturer for maximum wattage required.
Approximate Approximate Approximate Approximate
Starting Watts* Starting Watts* Starting Watts* Starting Watts*
Motor Approximate (Max. VA) (Max. VA) (Max. VA) (Max. VA)
HP Running Universal Motors Repulsion Capacitor Split Phase
Rating Watts (small appliance) Induction Motors Motors Motors
1/8 275 400 600 850 1200
1/4 400 500 850 1050 1700
1/3 450 600 975 1350 1950
1/2 600 750 1300 1800 2600
3/4 850 1000 1900 2600 †
1 1000 1250 2300 3000 †
1 1 /
2
1600 1750 3200 4200 †
2 2000 2350 3900 5100 †
3 3000 † 5200 6800 †
CHART 1
Installation (Continued)
NOTE: Some motors require nearly the
same wattage to run as to start. These
items include saws, drills, hair dryers, and
food mixers. See Chart 2 for typical
appliance wattage examples.
4. Add watts and starting watts (maximum
VA) of all items. This total must not be
larger than the rated wattage of your
generator. It is a good idea to have up
to 25% extra capacity for future needs
or extra equipment.
TYPICAL ELECTRIC APPLIANCE WATTAGES
Chart to be used as reference. Data may vary with size, make, and/or model.
CHART 2
Starting
Running Watts
Equipment Watts (Max.VA)
Light bulb (100W) 100 100
Radio 150 150
Fan 200 600
Television 400 400
Furnace fan—1/3 HP with blower 600 1800-2400
Vacuum cleaner 600 750
Sump pump—1/3 HP 700 2100-2800
Refrigerator/freezer 800 5000
6" Circular saw 800 1000
Floodlight 1000 1000
1/2" Drill 1000 1250
Toaster/coffeemaker 1200 1200
Skillet 1200 1200
14" Chain saw 1200 1500
Water well pump—1/2 HP 1000 3000-6000
Hot plate/range (per burner) 1500 1500
10" Table saw 2000 6000
Water heater (storage-type) 5000 5000
