MDS General-Purpose Board Development Kit
User Manual
UM016905-1207
Appendix—MDS-PM Board Pin Maps
54
I
2
C High Drive/Relay Control
I
2
C address: 0100000 R/W.
•
RELAY1—D0
•
RELAY2—D1
•
HD1-J20-1—D2
•
HD2-J20-2—D3
•
HD3-J20-3—D4
•
HD4-J20-4—D5
•
HD6-J20-5—D6
Digital Compass
Compass is not included.
•
NORTH—PB0_ANA0
•
EAST—PB1_ANA1
•
SOUTH—PB2_ANA2
•
WEST—PB3_ANA3
ADC Channels on Terminal Block J24
•
PIN 1—PB0_ANA0
POT R57 is hooked up to this channel.
•
PIN 2—PB1_ANA1
•
PIN 3—PB2_ANA2
•
PIN 4—PB3_ANA3
•
PIN 5— no connection
Note:
