Z8 Encore! XP ® F0822 Series Development Kit
User Manual
UM015009-0608 Z8 Encore! XP
®
F0822 Series Evaluation Board
6
Features
The features of Z8 Encore! XP F0822 Series evaluation board include:
• Z8 Encore! XP MCU (28-pin SOIC)
• 3 LEDs
• RS-232 interface
• IrDA transceiver
• Two pushbuttons–RESET and TEST
• 5 V DC power connector
• On-Chip Debugger (OCD) interface
• Crystal Oscillator at 18.432 MHz
• Header for ADC input
• Prototyping area
• External interface connectors JP1 and JP2
• 2.7 V to 3.6 V operating voltage with 5 V-tolerant inputs
MCU
Z8 Encore! XP F0822 Series is member of Zilog family of
microcontroller products based upon the 8-bit eZ8
TM core CPU. The Flash
in-circuit programming capability allows for faster development time and
program changes in the field. The eZ8 core CPU is upward compatible
with existing Z8
® instructions. The rich peripheral set of
Z8 Encore! XP F0822 Series makes it suitable for various applications
including motor control, security systems, home appliances, personal
electronic devices, and sensors.
The evaluation board contains circuitry to support and present all the
features of the Z8 Encore! XP F0822 Series.
