English - 29
Doing this will disable the Capture function. Suggest you return it to [Camera] mode after using this
function. Please follow the steps below.
1. Press [Menu] on the control panel to enter the setting menu.
2. Press [] or [] to the [Setting] menu.
3. Press [] to find [USB Transfer].
4. Press [] or [] to select [Camera].
5. Press [Menu] to exit.
Chapter 8 Connecting to Microscope
1. Mount the microscope adaptor onto the microscope.
Please choose an appropriate microscope adapter. Microscope adapter accessories are applicable to
eyepieces of Ø28mm, Ø31mm, Ø33mm, and Ø34mm.
2. The lens of 445 connects with the microscope adaptor.
3. Select the [Microscope] Mode
3.1. Press [M Scope] on the remote control (suggestion).
3.2. Control panel
3.2.1. Press [MENU] to enter the setting menu.
3.2.2. Press [] or [] to select [Display].
3.2.3. Press [] to select [Mode].
3.2.4. Press [] or [] to select [Microscope].
4. If the image is not clear.
4.1. Please adjust the focus of microscope.
If the eyepiece is Ø33mm or
Ø34mm, only one Lumens
microscope adapter is needed. If the eyepiece is Ø28mm or Ø31mm,
you need two microscope adapters.
(1. The original microscope adapter.
2. The microscope adapter suitable
for the eyepiece size Ø28mm or
Ø31mm.)
