Page 9
Page
Pos.
LT
-210
LT
-250
Part No.
Notes
Description
Specifications
4
1
1
381 100 600
FLEXIBLE PIPE UNIT
INCL. FIG. 16
4
2
1
388 100 503
FLEXIBLE SHAFT
4
3
1
388 300 200
GEAR CASE CPL.
INCL. FIG. 79 - 86 &109
4
4
1
388 501 200
CONTROL LEVER ASS'Y
INCL. FIG. 5 - 9
4
5
1
388 550 060
LEVER
4
6
1
388 550 070
CONNECTOR
4
7
1
388 500 900
SWITCH CPL.
4
8
2
388 004 992
TAPPING SCREW
4
9
1
388 004 991
TAPPING SCREW
4
10
1
388 400 300
HANDLE CPL.
4
11
1
388 950 020
SPACER
4
12
1
374 006 982
BOLT
4
13
1
388 370 600
FLANGE NUT
4
16
1
388 100 504
SPACER
4
17
1
388 003 990
CONTROL CABLE
4
67
1
388 604 700
CARBURETOR
INCL. FIG 87-100
4
68
1
367 114 996
TUBE
2.5X5X140
4
69
1
388 350 460
AIR CLEANER CASE
4
70
1
388 350 470
AIR CLEANER ELEMENT
4
71
2
388 360 565
SCREW
M5X62
4
72
1
388 350 450
CLEANER PLATE
4
73
1
388 350 420
GASKET
4
74
1
388 350 480
CHOKE LEVER
4
75
1
388 350 500
CHOKE PLATE
4
76
1
388 110 400
WASHER
4
77
1
388 004 998
TAPPING SCREW
M4X8
4
79
1
388 300 302
CUTTER SHAFT
4
80
1
388 300 203
BALL BEARING
608LLU
4
81
1
388 300 203
BALL BEARING
608LLU
4
82
1
388 300 205
WASHER
4
83
1
388 300 206
SPRING WASHER
4
84
1
388 850 080
RECEIVE WASHER
4
85
1
388 300 212
BOLT ASS'Y
4
86
1
388 700 510
C. R. HEAD BOLT
4
87
1
381 601 804
SWIVEL
4
88
1
381 600 811
PLUG
4
89
2
388 600 803
PAN HEAD SCREW
4
90
1
388 604 702
THROTTLE VALVE
4
91
1
381 600 512
RING
4
92
1
381 600 101
O-RING
4
93
1
381 600 201
JET
4
94
1
381 600 103
PUMP GASKET
4
95
1
381 600 104
PUMP DIAPHRAGM
4
96
1
381 600 401
INLET SCREEN
4
97
1
388 600 413
GASKET
4
98
1
381 600 525
METERING DIAPHRAGM ASS'Y
4
99
1
388 600 503
PRIMPER PUMP COVER
4
100
1
388 600 202
PAN HEAD SCREW
4
101
1
388 950 000
HOLDER
4
109
1
388 300 304
SPACER
4
400
1
388 800 600
PROTECTOR ASS'Y
4
401
1
381 224 262
TRIMMER HEAD
4
402
1
388 901 900
TOOL KIT
LT-250
