Page 3
Page
Pos.
LT
-210
LT
-250
Part No.
Notes
Description
Specifications
1
1
1
381 450 070
GRIP
1
2
1
381 502 800
CONTROL LEVER ASSY
INC. 3,5-12
1
3
1
381 501 811
WIRE SET
INC. 4
1
4
1
381 501 812
CONTROL CABLE
1
5
1
381 501 805
TUBE
1
6
3
381 350 530
SCREW ASSEMBLY
M5X30(SW)
1
7
1
381 501 806
LEVER SWITCH
1
8
1
381 501 813
SWITCH PLATE
1
9
1
381 501 803
LEVER
1
10
1
381 501 804
SPRING
1
11
1
381 502 803
TAPPINGU SCREW
5X12
1
12
3
367 180 500
NUT
M5
1
13
1
381 401 000
HANDLE ASSY
INC. 14,15
1
14
3
381 350 530
SCREW ASSEMBLY
M5X30(SW)
1
15
3
367 180 500
NUT
M5
1
16
1
381 951 180
CAUTION LABEL
1
17
1
381 101 900
FLEXIBLE PIPE UNIT
1
18
1
388 150 130
FLEXIBLE SHAFT
1
19
1
388 300 400
GEAR CASE ASSY
INC. 20-27
1
20
1
381 350 080
CUTTER SHAFT
1
21
2
388 350 060
BEARING BALL
#608ZZ
1
22
1
382 350 070
SPACER
1
23
1
388 700 510
CROSS RECESS HEAD BOLT
1
24
1
382 350 090
WASHER
1
25
1
381 350 100
WASHER SPRING
1
26
1
381 350 110
RECEIVE WASHER
1
27
1
388 300 212
BOLT ASS'Y
1
28
1
381 801 600
PROTECTER ASSY
1
29
1
367 951 470
CAUTION LABEL
1
30
1
381 150 150
SPACER
