Page Pos.
LT
-210
LT
-250 Part No. Notes Description Specifications
2 31 1 381 350 280 SPACER GASKET
2 32 2 388 005 950 SCREW M5X25
2 33 1 381 301 400 INSULATOR COMPL.
2 34 1 381 550 020 WIRE
2 35 1 377 350 050 INSULATOR GASKET
2 36 2 382 905 973 SOCKET HEAD BOLT M5X20
2 37 1 388 750 010 PLUG CAP COVER
2 38 1 374 014 971 SPARK PLUG
2 39 1 381 150 090 CYLINDER
2 40 1 381 550 310 CYLINDER COVER
2 41 1 381 950 810 TRADE MARK LABEL "DOLMAR"
2 42 1 388 005 979 TAPPING SCREW 5X14
2 43 1 388 500 987 PLUG CAP
2 44 1 377 400 993 PLUG CAP SPRING
2 45 1 374 108 995 TUBE
2 46 1 374 701 800 WIRE COMPL
2 47 2 381 004 977 SCREW ASSY M4X16(W,SW)
2 48 1 374 701 101 IGNITION COIL
2 49 2 367 905 952 SOCKET HEAD BOLT M5X40
2 50 1 368 300 100 EXHAUST MUFFLER INC. 51
2 51 1 374 300 105 SPARK ARRESTER
2 52 1 383 350 000 INSULATOR,MUFFLER
2 53 1 382 150 030 CYLINDER GASKET
2 54 1 374 250 050 PISTON RING
2 55 1 388 508 997 CLIP
2 56 1 374 250 170 PISTON
2 57 1 367 250 050 PISTON PIN
2 58 1 388 508 997 CLIP
2 59 1 388 200 100 CRANKSHAFT COMPLETE
2 60 3 381 004 977 SCREW ASSY M4X16(W,SW)
2 61 1 381 500 900 REWIND STARTER INC. 62-69
2 62 1 367 550 000 PULLEY
2 63 1 367 500 206 SET SCREW
2 64 1 367 500 210 SWING ARM
2 65 1 367 500 211 COLLAR
2 66 1 383 500 203 REEL
2 67 1 381 500 205 SPIRAL SPRING
2 68 1 388 500 402 HANDLE
2 69 1 388 501 602 STARTER ROPE
2 70 1 381 950 810 TRADE MARK LABEL "DOLMAR"
2 71 1 383 100 400 CRANK CASE ASS'Y INC. 72-75
2 72 2 374 010 998 OIL SEAL
2 73 1 318 150 040 CRANKCASE GASKET
2 74 2 381 010 998 BALL BEARING 6000
2 75 3 388 005 952 SCREW M5X25
2 76 1 374 701 701 FLYWHEEL
2 77 1 381 200 600 CLUTCH
2 78 1 381 201 100 CLUTCH DRUM COMPLETE
2 79 1 374 100 600 CLUTCH CASE COMPLETE
2 80 1 374 151 000 OUTER SNAP RING 10
2 81 1 383 905 988 SOCKET HEAD BOLT M5X25
2 82 1 374 150 020 PIPE DAMPER
2 83 1 374 150 130 PIPE BRACKET
2 84 1 374 605 998 CLAMP
2 85 3 374 005 978 TAPPING SCREW M5X20
2 86 1 374 905 985 SOCKET HEAD BOLT M5X14
2 87 1 377 605 900 FUEL TANK CAP COMPLETE INC. 88,89
2 88 1 374 605 800 FUEL TANK CAP
2 89 1 374 606 700 STRAP
2 90 1 382 650 000 FUEL TANK
2 91 1 374 115 992 TUBE
2 92 1 381 105 999 HOSE CLAMP
2 93 1 382 650 390 FILTER
2 94 1 381 650 020 PLATE
2 95 1 381 650 030 PLATE
2 96 1 383 350 010 PLATE
2 97 2 381 650 025 DAMPER
LT-210
